WiFi Temperature Data Logger with Thermocouple Probe Corintech WiFi-TC

New product

The WiFi-TC Temperature Data Logger with Thermocouple Probe measures the temperature of the environment in which the probe is situated. Data is transmitted wirelessly via a WiFi network to a PC and viewed using free Software available to download.

More details

In stock

156,56€ tax excl.

Add to wishlist

More info

Key Features:

  • Measurement range -270°C to 1300°C / -454°F to 2372°F (probe dependent)
  • Rechargeable internal lithium polymer battery
  • Easy data logger set-up using free PC software application
  • Temperature data logger with K type thermocouple probe
  • Supports J, K, N, T type probes
  • Temperature selection in °C or °F
  • Data can be viewed via the graphing tool or can be exported to MS Excel
  • Configurable high and low alarms with indicator
  • Wireless connectivity to PC via WiFi
  • Max and Min readings
  • IEEE 802.11b/g/n compliant
  • Protection rating IP55
  • Capable of logging greater than 1 million data entries
  • Memory stores all data even if WiFi is temporarily disconnected
  • Fully featured LCD segment display
  • Low battery indicator
  • WiFi connection indicator
  • USB port used for recharging (can only be recharged when the unit
  • is between 0 to 40°C / +32 to 104°F
  • Supplied with removable thermocouple probe, micro USB lead, USB cable, wall-mounting bracket, Quick Start Guide
  • Easy sensor set-up using free PC software application (Download your free software here)
  • Wirelessly stream and view data via WiFi on PC or FilesThruTheAir™ Cloud
  • View and analyse multiple sensors, including graphing of historic data
  • Optional calibration check certificate using IPAC traceable reference

Sistema WiFi

During configuration the Data Logger will search for an existing wireless network while physically connected to the PC. It can then be placed anywhere within range of the network.

If the Data Logger temporarily loses connectivity with the network, it will log readings until it is able to communicate again with the PC application (max 120 days at 10 second sample interval). The range of the Data Logger can be increased by using WiFi extenders.

The WiFi-TC Data Logger is supplied with a Thermocouple Probe and can be used with a range of probes from Corintech in a variety of food production and food service temperature applications.

This WiFi-TC Temperature Data Logger with Thermocouple Probe is a low powered battery device with a battery life of 3 months to one year, depending on transmission rate. The battery can be recharged via a PC or by Power Supply Unit, which is available as an accessory.

Example of internet connections based on Cloud system

Internet connection

Other Features:

  • Multiple user accounts
  • Multiple site mitoring
  • Email alerts
  • Store data online
  • View on mobile devices
  • Optional security enhancements

Other Features

Note: If you select Accredited Calibration Certificate (IPAC) when purchasing this product, click the Product Customization TAB and fill in the second field (TEXT - Required temperature calibration points.) with the respective required points or simply attach a copy of a calibration certificate.
