MiniFlash Infrared thermometer Dostmann 5020-0414 View larger

MiniFlash Infrared thermometer Dostmann 5020-0414

New product

The MiniFlash thermometer is a non-contact infrared thermometer. Simply aim at the target and press the measure button to display the surface temperature instantly. The MiniFlash indicates temperature over the range of -33 to 220°C with an assured accuracy of ±2°C.
HACCP

More details

40,32€ tax excl.

Add to wishlist

More info

Key Features:

  • Temperature range: -33 to +220°C
  • Field of view 1,3: 1
  • Wide temperature range
  • Fixed emissivity 0,95
  • Non-contact surface temperature measurement, ideal in the food sector
  • Accurately, clean and fast temperature measurement
  • Lets you check the cold chain in storage and transport
  • Measurement in just 1 seconds

The MiniFlash infrared with distance to target ratio 1.3:1 and therefore the thermometer should be positioned as close to the target as possible. The default emissivity is 0.95.

Note: If you select Accredited Calibration Certificate (IPAC) when purchasing this product, click the Product Customization TAB and fill in the second field (TEXT - Required temperature calibration points.) with the respective required points or simply attach a copy of a calibration certificate.

To optimize surface temperature accuracy:

  1. Determine the emissivity of the object to adjust the spectrum range of the instrument that can be used for measurement.
  2. Avoid reflection from other sources of temperature by thermally enveloping the object to be measured
  3. For high temperature objects, use smaller wavelength instruments when possible.
  4. For semi-transparent materials such as plastic films and glass, make sure that the bottom surface (behind the object) is uniform and below the temperature of the object.
  5. Hold the instrument perpendicular to the surface of the object when the emissivity is below 0.9.
  6. In all cases, do not exceed the 30 degree angle of incidence.
