Fast Screening CDP 7000 Breathalyzaer

Equipped with cutting-edge fuel cell electrochemical sensor technology, this device offers precision, reliability, and instant response, even in high-traffic control situations.

Maximum Reliability with International Certification
All our devices are supplied with an official calibration certificate with ENAC traceability (https://ilac.org/), internationally recognized by most metrology institutions. This guarantees full compliance with the highest standards of quality and technical accuracy.

Ergonomic Design and Intuitive Use
The CDP 7000 features a compact keypad and a highly intuitive menu, enabling quick and simple operation even in demanding environments. Its color LCD screen ensures excellent visibility both day and night, enhanced with LED warning indicators and a white light beam for greater user comfort and safety.

Its lightweight design and hygienic blow aperture make this device particularly well-suited for frequent testing, ensuring both efficiency and hygiene.

High-Throughput Testing: Over 20 Tests Per Minute
Designed for high-volume control operations, the CDP 7000 allows for more than 20 tests per minute, with or without mouthpieces. This not only reduces operational costs but also increases field productivity. The device has proven essential in intensive control settings, such as during recent roadside checks by the Policía Foral during the San Fermín festival, where 875 tests were conducted in just 90 minutes — with speed, efficiency, and minimal disruption to drivers.

Main Advantages

• State-of-the-art fuel cell electrochemical sensor technology
• High accuracy and reliability in alcohol detection
• User-friendly interface and rapid operation
• Optimal visibility under any lighting conditions
• More than 20 tests per minute, with or without mouthpieces
• ENAC-traceable calibration certificate included
• Ideal for law enforcement, transport companies, industry and workplace prevention programmes

Key Features

The CDP 7000 allows alcohol testing with or without mouthpieces, thanks to its innovative design that collects breath samples without direct contact with the device.

It is compatible with the standard mouthpieces used by law enforcement and traffic agencies in Spain, as well as with our universal mouthpieces, manufactured from high-density polypropylene and fitted with non-return valves to maximise hygiene and safety by helping prevent the spread of infectious diseases.

Additional Functionalities:

• Automatic calibration reminder (recommended every 6 or 12 months)
• Real-time battery level display
• User-configurable alarm thresholds
• Modular electrochemical sensor: swappable and recalibratable
• Auto shut-off function for energy saving

Technical Specifications

• Measurement range: 0 to 2.000 mg/L (0 to 440 mg/100ml)
• Warm-up time: Not required (instant readiness)
• Response time: < 1 second
• Continuous testing capacity: 1,000 – 2,000 tests (with full batteries)
• Standard deviation: 0.008 mg/L
• Alarm threshold: Adjustable from 0.200 to 0.600 mg/L
• Blow time: Configurable from 1 to 6 seconds
• Post-blow response time: < 10 seconds
• Operating temperature: -10ºC to +50ºC
• Storage temperature: -20ºC to +60ºC
• Relative humidity: 20% to 90%
• Atmospheric pressure: 700 to 1300 hPa
• Technology: 16-bit low-power MCU
• Sensor: Fuel cell electrochemical sensor — highly accurate and durable

User Interface and Operation

• Color LCD display, clear and easy to read, with 4-digit results and user messages
• Blue backlight for nighttime use
• Visual (red LED) and acoustic alarms for high visibility
• Real-time display of current temperature and date
• Energy-saving mode with automatic power-off
• Adjustable measurement units and alarm thresholds
• Virtually zero warm-up time, enabling fast, uninterrupted testing

Power Supply and Physical Specs

• Powered by four 1.5V AA batteries (supports 1.2V Ni-Cd rechargeable batteries)
• Dimensions: 284 mm x 69 mm x 74 mm
• Weight: 400 g

Package Contents

• CDP 7000 Fast Screening Breathalyzer
• User manual
• Inspection and calibration certificate
