New

High-Precision Vacuum / Barometer with Pressure Port

View larger

Display all pictures

High-Precision Vacuum / Barometer with Pressure Port

Reference: ECO 240-1

Condition: New product

ECO 240-1 - High-Precision Vacuum / Barometer with Pressure Port

Brand: Senseca

The ECO 240-1 was developed with a focus on core measurement functions. At its heart is a high-quality sensor – no compromises were made despite the device's affordable price point.

Write a review

Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

More info

Key Benefits

German-engineered high-precision sensor
Fast and accurate pressure and vacuum readings
Fine resolution down to 1 mbar
Rugged, waterproof housing (IP67)
Three-line backlit display with battery indicator
Min/Max/Hold functions and configurable auto shut-off
Perfect for vacuum packaging machines and molding processes

Typical Applications

Testing and verifying vacuum packaging machines
Monitoring vacuum molding processes
Use as a reference-grade barometer or vacuum meter

Technical Highlights

Technical Specifications – ECO 240-1
Protection class	IP67 (waterproof and dustproof)
Measurement rate	Slow: 2.5/s \| Fast: 25/s
Power supply	2 x AA alkaline batteries (included)
Power consumption	< 1 mA without backlight / ~3 mA with backlight
Weight	140 g incl. batteries
Auto power-off	User-configurable
Housing material	Break-proof ABS, polyester front panel
Measurement range	0.0 … 1700.0 hPa (mbar)
Typical precision @ 25 °C	±2 hPa (±1 hPa @ 0...20 hPa)
Max. precision (-20 to +50 °C)	±1.25 % FSS
Pressure connection	1 tube (G1/8 universal, interchangeable)
Display units	hPa, mbar, PSI, mmHg (Torr)
Operating temperature	-20 … +50 °C (recommended: 5 … 30 °C)
Additional features	Sea level correction, NULL/Tare, averaging (AVR), Min/Max/Hold
Battery life	~3000 h typical (without backlight)
Optional certification	Calibration certificate available
