Frying Oil Monitor - DOM-24 Atago

DOM-24

New product

Control frying oil with precision:

TPM/AV readings, NFC export, ATC 0–225°C, IP67, IH compatible. Improve flavor, safety and cut costs.

Quantitative, reliable management of deteriorated oil. IoT-ready with NFC* for traceability and audit trails.

Frying Oil Monitor TPM & AV ATC 0–225 °C 100-reading memory IH compatible (patented) Washable & hygienic IoT / NFC*

More details

584,90€ tax excl.

Add to wishlist

More info

Why DOM-24

Once frying oil breaks down, it must be replaced. Using degraded oil increases costs, harms flavor and texture, and may impact customer health. DOM-24 gives objective, repeatable readings (TPM & AV) so you can change oil at the right time — cutting waste while protecting food quality.

Key benefits

  • Reagent-free, zero waste — no titration kits, strips or disposables.
  • Objective & precise — quantitative values, not operator-dependent.
  • Safe & hygienic — washable sensor/body; no chemicals near food.
  • Stable at high temperatureATC from 0–225 °C.
  • IoT traceability — up to 100 measurements; export via NFC* to smartphone/PC.
  • Induction-ready (IH) — unique oil checker for IH when using the sensor cover (patented).

Where it excels

  • Restaurants, QSR, ghost kitchens, takeaway.
  • Bakeries, cafés, street food vendors.
  • Central kitchens and food manufacturing.
  • Hotels, catering, institutional food service.
  • Quality audits & HACCP programs.

Identifying oxidized cooking oil

Professional kitchens rely on recognized indices to quantify oxidation and freshness:

  • Total Polar Materials (TPM) — total polar compounds from oxidation and polymerization (incl. FFAs and low-MW breakdown products). In the EU, 25–27 % is widely adopted as the upper limit for frying fats/oils.
  • Acid Value (AV) — free fatty acids from hydrolysis; common in Japan/USA for freshness/oxidation assessment.
  • Carbonyl Value (CV) — aldehydes/ketones from thermal oxidation; strong link to rancid odors.
  • Peroxide Value (POV) — hydroperoxides formed during initial oxidation of unsaturated fatty acids.

DOM-24 measures both TPM and AV, letting you align with regional standards and internal policies.

Features & Specs

FeatureDetails
Measurement modesTPM % and AV (switchable) — choose the most suitable scale.
Temperature range0–225 °C with ATC — reliable results even when hot.
IoT / HistoryStores up to 100 readings; read via NFC* using a contactless IC reader/writer connected to a smartphone or PC.
Hygiene & safetyNo reagents, no waste; fully washable; safe distance from hot oil to protect hands.
IH compatibilityThe only oil checker usable on induction (IH) with the sensor cover (patented).
RecognitionFSSAI (India) selected DOM-24 in 2019 as an innovative product contributing to food safety.
PatentsJP: PAT#6435565, PAT#6395243, PAT#6471300  |  TW: PAT# I574004  |  KR: PAT# 10-1975308  |  CN: ZL 2019 9 0000638.1

* The N-Mark is a trademark or registered trademark of NFC Forum, Inc., in the United States and other countries.

DOM-24 Acid Value (AV) scale model also available.

Product Information

ItemDetails
ModelDOM-24 X3
Cat.No.9347
RangeTotal Polar Materials (TPM): 0.5 to 40.0 %
Acid Value (AV): 0.00 to 9.99
ResolutionTPM: 0.5 %
AV: 0.01
Temperature: 1 °C / 1 °F
AccuracyTPM: ±2.0 % (20 to 200 °C / 68 to 392 °F)
AV: ±0.2
Temperature: ±1 °C / ±2 °F
Power Supply2 × AAA alkaline batteries
International ProtectionIP67
Dimensions & Weight22(Φ) × 490(W) mm, 400 g (main unit only)
