D•CAN Gen2 | Addressable Oxygen Detector

The D•CAN Gen2 is an oxygen detector built to monitor oxygen (O₂) in industrial and commercial settings. When connected to S•Vx or S•Lx control units, it can trigger air extractors, sirens, and other safety systems—helping you act before concentrations reach hazardous thresholds.

More details

397,00€ tax excl.

Add to wishlist

More info

Key Benefits & Differentiators

  • CAN-bus addressable network: digital readings and easier maintenance across multi-sensor installations.
  • Control-unit integration: supports automated ventilation and alarm strategies via S•Vx / S•Lx panels.
  • Multicolor LED status: Green (normal), Yellow (fault), Red (danger).
  • Rugged design: flame-retardant (UL 94 V-0), UV-stabilized housing with IP65 ingress protection.

Applications

Recommended for underground parking garages, laboratories, and commercial/industrial buildings requiring multiple sensors on an addressable network. Suitable for areas where an explosive atmosphere is unlikely during normal operation or only occurs for short periods.

Characteristics & Technical Data

D•CAN Gen2 — Specifications
Measurement principle (EC)Electrochemical (EC)
Power consumption (EC)0.14 W
Operating temperature (EC)-20 °C to +40 °C
Humidity & pressure10 to 90% RH (non-condensing) | 90–110 kPa
Wiring* CAN2 x 2 x 0.75 mm² shielded or Ethernet S/FTP 0.25 mm²
Cable entry2 x M16
Housing ingress protectionIP65
Housing materialFlame-retardant (UL 94 V-0) and UV-stabilized plastic
Dimensions (H x W x D)142 x 119 x 51 mm
Weight300 g
OutputDigital (CAN bus)
Operating voltage10 – 30 VDC
CertificationsElectromagnetic compatibility (EMC): EN 50270 (type 2)
Gas detection for parkings & tunnels: EN 50545-1
Functional safety of digital components: EN 50271
Target gasOxygen (O₂)
Sensor technologyEC (electrochemical)
Range0 – 25% vol.
Accuracy± 1.5% FS
Response time (T90)< 10 s
Expected sensor life2 years
