Description

Compact, reliable and easy to use, this standalone logger can store up to 32,510 readings over a 3 to 1000 ppm measurement range, making it an efficient solution for environmental control, maintenance and technical reporting.

With direct USB connectivity and setup through the free EasyLog software, the EL-USB-CO streamlines the full monitoring process: configure the logger, start recording, download readings, view graphs and export reports to Excel, PDF and JPEG. It is an excellent choice for professionals who need reliable carbon monoxide monitoring, configurable alarms and accurate historical data for documentation and analysis.

Key Benefits

• 3 to 1000 ppm CO measurement range for professional air monitoring
• Stores 32,510 readings for long-term data logging applications
• User-selectable logging intervals from 10 seconds to 5 minutes
• Status LEDs for quick visual indication of operation and alarm state
• Built-in audible buzzer for immediate alarm notification
• USB interface for simple setup and fast data download
• Free EasyLog software for graphing, export and reporting
• Immediate or delayed logging start for flexible deployment
• User-programmable high and low alarms to match application needs

Why Choose the EasyLog EL-USB-CO?

The EasyLog EL-USB-CO combines ease of use, large memory capacity, portable form factor and technical accuracy in one practical monitoring device. Compared with more complex or higher-cost systems, it offers straightforward deployment for professionals who need documented carbon monoxide data logging without unnecessary complexity.

It is especially suitable for technical audits, preventive maintenance, indoor air quality assessments and environmental monitoring, helping users make informed decisions based on real, exportable and easy-to-interpret measurement data.

Typical Applications

• Carbon monoxide monitoring in commercial and technical buildings
• Indoor air quality monitoring
• Inspection of plant rooms and combustion-related areas
• Boiler, burner and heating system maintenance
• Environmental safety monitoring in enclosed spaces
• Parking garages, warehouses and service areas
• Safety audits and environmental studies
• Data logging for technical reports and compliance documentation

Product Description

This standalone CO data logger measures and stores up to 32,510 carbon monoxide readings over a 3 to 1000 ppm range, with an operating temperature range of -10°C to +40°C. Logger setup and data retrieval are quick and straightforward through a PC USB port using the EasyLog control software.

Recorded data can be graphed, printed or exported to other applications for detailed analysis. The unit is supplied with a 1/2 AA battery and a wall mount clip, making it ready for professional use straight out of the box.

Important Safety Notice

The EL-USB-CO is a professional instrument intended to measure and record carbon monoxide levels in air over time. It takes sample readings at defined intervals for monitoring, recording and analysis purposes. It is not a suitable replacement for a domestic or industrial carbon monoxide detector or alarm.

Sensor Life

The typical sensor life of the EL-USB-CO is 4 years. The exact expiry date can be checked in the EasyLog software under Current Status.

Technical Specifications

EasyLog Software

Lascar’s EasyLog software is available as a free download and is designed to make logger setup and data management simple and efficient. Compatible with 32-bit and 64-bit versions of Windows 7, 8 and 10, it allows users to configure the logger, download readings, create graphs, add annotations and export files in Excel, PDF and JPEG formats.

Configurable software parameters include:

• Logger name
• Logging interval between 10 seconds and 5 minutes
• High and low alarms
• Immediate or delayed start

Frequently Asked Questions

Can the EL-USB-CO be used as a CO alarm?

No. The EL-USB-CO is a professional monitoring and recording instrument for technical analysis. It does not replace a domestic or industrial carbon monoxide detector or alarm.

How many readings can it store?

This logger can store up to 32,510 readings, making it suitable for extended monitoring and data logging projects.

How is the data reviewed?

Data is downloaded via USB and reviewed in the EasyLog software, where it can be graphed, annotated, printed and exported to Excel, PDF and JPEG.

What is the expected sensor life?

The expected sensor life is typically 4 years. The exact expiry date is available within the software under Current Status.
